(PU) Premium Engineered Vinyl WPC 8mm 20mil

PU601 Bonita Springs

Characteristics	Standards	Requirements	Result
TUV Premium Certification	Belgian VOC regulation BREEAM Exemplary Level	Refer to Standards	Pass
CE Certification	EN14041	Refer to Standards	Pass
Floorscore Certification	SCS-EC10.3-2014v3.0	Refer to Standards	Pass
Castor Chair Resistance	NALFA LF 01-2011 Section 3.9	N/A	After 25000 cycles,test specimens no visible damage
Dimensional Stability	ASTM F2199-09(2014) Heating temperature:65oC	≤0.25%	MD:=-0.092% AMD:=-0.030%
Pentachlorophenol(PCP)	With reference to PD CEN/TR 14823:2003	N/A	Free
Formaldehyde Emission	EN 717-1:2004	E1≤0.124mg/m³	Free
Fire resistance	EN ISO 9239-1 EN ISO 11925-2 EN 13501-1:2010	N/A	Bfl-S2
Impact insulation	ASTM E2179-09	N/A	IICC-28=∆IIC 24
Impact resistance	ASTM F1265-03a(2013)	N/A	No crack
Phthalate tests (DBP/BBP/DEHP/DINP/ DNOP/DIDP)	REACH NO.1907/2006	N/A	Free
Resistance to Heat	ASTM F1514-03(2013)	△E* shall not greater than 8.0 after7 days exposure to 70°C	△E*=0.66
Residual indentation	ASTM F1914-07(2011)	Average≤8% Max≤10%	Average≤6.6% Max≤7.4%
Slip resistance	EN 13893:2003	EN 14041:μ≥0.3	μ=0.36 Class DS
Density	ASTM D792-13 Method A,Water at 23°C	N/A	1.15g/cm³
Squareness	ASTM F2055-17	≤0.25mm/305mm	Pass
Size	ASTM F2055-17	A tolerance of ±0.4mm/305mm	Pass
Thickness	ASTM F386-17	A tolerance of ±0.13mm	Pass
Thermal Conductivity	ASTM C518-10	N/A	0.114 W/(m.K)
Thermal Resistance	ASTM C518-10	N/A	0.062(m².K)/W
