| Length | 48″ | Width | 7.25″ |
| Thickness | 2.0mm | Wear Layer | 12mil |
| Finishing | Wood Emboss | Edge Description | Micro Bevel |
| Sqft/Ctn | 58.00 | Lbs/Ctn | 47.0 |
| Ctn/Plt | 60 | Sqft/Plt | 3,480 |
| No. | Description | Method | Standard | Result | Performace Rating | |
| 1 | Packing Appearance | Internal | Pallets/Cartons/Labels/Inserts/Bar Codes match customer order in quality and quantity, with neat appearance. | Pass | Better | |
| 2 | Product Appearance | Internal | Material must match customer order. No print film folding, no rough bevel, no bevel with white line, no film scratch or breakage, no color difference, no wear layer bubbles, no impurities, no stains, no dents, no scratches, no broken corners, no fish eyes, no trash, no holes, no hair/ foreign subject, no overhang or uneven backpad, etc. | Pass | Better | |
| 3 | Dimensions | Length | ASTM F1700 | ± 0.40 mm | 0.1mm | Better |
| Width | ± 0.10 mm | 0.05mm | x | |||
| 4 | Overall Thickness | ASTM F1700 | ± 0.10 mm | 0.05mm | Better | |
| 5 | Squareness | Length | ISO 24342 | ≤0.25 mm | 0.03mm | Best |
| Width | ≤0.25 mm | 0.02mm | Best | |||
| 6 | Straightness | Length | ISO 24342 | ≤0.25 mm | 0.05mm | Best |
| Width | ≤0.25 mm | 0.01mm | Best | |||
| 7 | Stitching Gap (mm) | EN13329 | ≤0.20 mm | 0.05mm | Best | |
| 8 | Height Difference | EN13329 | ≤0.15 mm | 0.05mm | Best | |
| 9 | Wear Layer Thickness | EN 429 | ± 0.02 mm | 0.01mm | Best | |
| 10 | Peel Strength of Adhesive Bonds | ASTM D903 | ≥5.5Lbs/Inch | 9Lbs/Inch | Best | |
| 11 | Scratch Resistance | EN 16094B | > 2500g | 4,000g | Best | |
| 12 | Micro-Scratch Resistance (A & B) | EN 16094 | MSR-B1 – B3 | MSR-B2 | Better | |
| 13 | Coating Adhesion (Cross hatch) | EN 16094B | 5B | 5B | Best | |
| 14 | Abrasion Resistance of Organic Coatings by the Taber Abraser | ASTM D4060 | No pass-fail criteria | Abrasion Wheel H-18 Load Applied 1000 Grams Number Of Cycles:14000 | Best | |
| 15 | Determination of Dimensional Stability and Curling after Exposure to Heat (6h – 176F) | ISO 23999 ASTM F3261 | Length mean ≦0.25％ Width mean ≦0.25％ | Length mean =0.02％ Width mean =0.04％ | Best | |
| 16 | Wear Layer Abrasion Resistance | EN 13329 (S-42, 200 cycle change) | IP≥1,800 cycles | No abrasion through wear layer into print film upon cycle completion. | Better | |
| 17 | Density | ASTM D2395 | 1.9-2.2g/cm³ | 1.92g/cm³ | Good | |
| 18 | Phthalates | CPSC-CH-C1001-09.4 | GC-MS analysis each substance ≤ 50ppm | < 1.0ppm | Best | |
| 19 | Heavy Metal Content Analysis | ASTM F963 | Antimony < 60 ppm, Arsenic < 25 ppm, Barium < 1000 ppm, Cadmium < 75 ppm, Chromium < 60 ppm, Lead < 90 ppm, Mercury < 60 ppm, and Selenium < 500 ppm | All < 0.25ppm | Best | |
| 20 | Gloss Level (gu) | ASTM D523 | ±2gu | < ±2gu | Good | |
| 21 | Resistance to Chemicals | ASTM F925 | 0 – No change (—-) 1 – Slight change 2 – Moderate change 3 – Severe change | 0 No Change | Good | |
| 22 | Determining Resistance of Synthetic Polymers to Fungi | ASTM G21 | Rating 0: No Fungal Growth on Sample Rating 1: Trace of Growth (< 10% coverage) Rating 2: Light Growth (10-30% coverage) Rating 3: Medium Growth (30-60% coverage) Rating 4: Heavy Growth (60-100% coverage) | Rating 0, No Fungal Growth on Sample | Best | |
| 23 | Smoke Density (Non-Flaming) | ASTM E662 | ≦450 | 291 | Best | |
| 24 | Smoke Density (Flaming) | ASTM E662 | ≦450 | 237 | Best | |
| 25 | Calculated Sound Transmission (STC) | ASTM E90-09 (2016) ASTM E413-16 | No pass-fail criteria | 52 | Good | |
| 26 | Impact Sound Reduction (IIC) | ASTM E492-09 ASTM E989-18 | No pass-fail criteria | 62 | Good | |
| 27 | Short-Term Indentation and Residual Indentation of Resilient Floor Covering | ASTM F1914 ASTM F3261 | ≤ 0.007 inch Surface Integrity: No puncture through wear layer/print film into rigid core. | 0.002 inch No puncture through wear layer/print film into rigid core. | Best | |
| 28 | Static Load Limit | ASTM F970 | Max loading: 250psi Max residual indent: 0.005 inch | 0.003 Inch @ 250psi | Good | |
| 29 | Heat Stability of Resilient Flooring by Color change | ASTM F1514 | < 8.0 ΔE | 0.05-0.19 ΔE | Best | |
| 30 | Light Stability of Resilient Flooring by Color change | ASTM F1515 | < 8.0 ΔE | 0.29-0.46 ΔE | Best | |
| 31 | Static Coefficient of Friction | ASTM C1028 | ≥ 0.60 for dry surfaces ≥ 0.53 for wet surfaces | Dry 0.69 Wet 0.56 with 50lbs load | Good | |
| 32 | Fire resistance | EN 9239-1 EN ISO11925-2 EN 13501-1 | Critical Fluxf≥8.0kW/m² Fs≤150mm within 20s Smoke≤750% minutes | Bfl-S1 | Better | |
| 33 | Formaldehyde Emission | EN717-1:2004 | ≤ 0.05 ppm | ＜0.002 ppm | Best | |
| 34 | TVOC | ASTM CA 01350 v1.1,2012 | 0.5 mg/m³ or less | 0.064 mg/m³ | Best | |
